Product Overview

  Various inverters, rectifiers, high-frequency generators, laser generators, and various inductive motor loads in the power grid system cause additional waveform distortion and voltage fluctuations, which threaten the electricity safety of many precision and high-value equipment, resulting in direct or indirect electricity hazards, and even equipment damage. The Kinbo SBW-SG series is a customized non-standard voltage-stabilizing integrated power supply designed for different industries. This power supply can meet the voltage conversion and stabilization needs of both domestic and foreign equipment, and can also be designed for electrical isolation and voltage stabilization according to the local power grid environment. The output terminal is isolated from the input terminal ('circuit break'), allowing the creation of a new neutral-ground connection to eliminate common-mode interference and other neutral line issues in the power grid. The isolation transformer converts three-phase delta wiring to a four-wire Yo system, and by adding electrostatic shielding further eliminates high-frequency pulse interference internal to the transformer, enhancing isolation and anti-interference performance. This power supply integrates voltage stabilization and transformation in one unit, with a compact size, convenient installation, high voltage stabilization accuracy, fast response, strong load impact resistance, good stability, and comprehensive protective functions.

Technical Parameters

Features

High Voltage Stabilization Accuracy: Uses RMS true effective value sampling control board, with adjustable stabilization accuracy of 1~5%.
Fast Adjustment Speed: Machine tool slider conduction technology, response time ≤0.04s, stabilization time<1.2s.
Comprehensive Protective Functions: Provides over-voltage, under-voltage, over-current, short-circuit, overheat, and phase-loss protections.
Wide Voltage Stabilization Range: Standard ±20%, customizable ±30%~±50%.
High Overall Efficiency: Stabilizer efficiency ≥98%.
Stable Control Technology: MCU measurement and control with metering chip design ensures precise and stable system performance.
Excellent Output Waveform: Output voltage waveform is distortion-free and harmonic-free.
High-Quality Materials: 0.35mm high magnetic-conduction, low-loss coated silicon steel sheet, C1017 alloy brushes.
High Level of Automation: Fully automatic voltage stabilization, delayed start, and automatic recovery after fault removal.
Large Load Capacity: Stabilizer capacities from 1KVA to 3600KVA available.

Broad Load Compatibility: Suitable for any type of load.
Comprehensive Communication Functions: RS485RS232GPRS optional.
