Intro：The KB SBW and KBDBW series AC compensating voltage stabilizers (hereinafter referred to as stabilizers) are power products developed and designed by our company in response to the current situation of China's national power grid. They can automatically maintain a stable output voltage when fluctuations in the external power supply network or changes in the load cause voltage fluctuations.
Product Details:
Product Overview
The KB SBW and KBDBW series AC compensation voltage stabilizers (hereinafter referred to as stabilizers) are power supply products developed and designed by our company in response to the current national power grid conditions in China. They can automatically maintain stable output voltage when voltage fluctuations occur due to external power supply network changes or load variations. Compared with other types of stabilizers, this series of products has advantages such as large capacity, high efficiency, no waveform distortion, and smooth voltage regulation. They are suitable for a wide range of loads, can withstand instantaneous overload, can operate continuously for long periods, support manual/automatic switching, and are equipped with overvoltage protection, phase loss, phase sequence protection, and automatic mechanical fault protection. The machines are reliable, compact, lightweight, and easy to install and use.
Technical Parameters
| Capacity Range | Three-phase capacity: KBSBW-20~3600KVA; Single-phase capacity: KDBW-10~500KVA |
| Input Voltage | Three-phase 380Vac±20%; Single-phase 220Vac±20%; Customizable ±30% ±40% |
| Output Voltage | Three-phase 380Vac single-phase 220Vac;The output voltage can be customized according to customer requirements, 如200V 208V 400V |
| Voltage Regulation | 1%~5% adjustable |
| Frequency Range | 50Hz/60Hz |
| Efficiency | 98% (Power rating 50KVA and above) |
| Response Time | ≤0.04S |
| Stabilization Speed | Input voltage changes by ±10% of the rated value, stabilization time ≤1S |
| Insulation Resistance | ≥2MΩ |
| Withstand Voltage | 2000V for 1 minute without breakdown |
| Waveform Distortion | The output voltage waveform compared with the input voltage waveform, the harmonic content does not exceed 1% |
| Communication Function | Optional RS232, RS485, GPRS interface, support remote monitoring and control function |
| Display Function | LCD high-brightness display, can display input/output voltage, current, frequency, temperature and fault alarm status, etc. HMI human-machine interface touch screen display (optional) |
| Protection Function | Over-voltage, under-voltage, over-load, short-circuit, phase loss, reverse phase, over-temperature and other protection alarms, and automatic recovery after fault |
| Operating Temperature | -15°C + 45°C |
| Relative Humidity | 10%~90% (20°C ± 5°C) |
| Altitude | < 2000m, above standard altitude, according to GB6450 "Power Transformers" Chapter 3.2.3 and 4.2 derating |
| Protection Rating | IP21, customizable IP45 and below protection rating |
| Noise | < 60dB |
| Execution Standard | YD/T 1074-2000 "Communication AC Stabilizer", JB/T 7620 - 1994 "AC Stabilizer" |
Features
High voltage regulation accuracy: Uses an RMS true value sampling control board, with adjustable voltage regulation accuracy of 1~5%.
Fast response: Machine slide conduction technology, response time ≤0.04S, stabilization time<1S.
Comprehensive protection: Provides overvoltage, undervoltage, overcurrent, short circuit, overheating, and phase-loss protection.
Wide voltage regulation range: Standard ±20%, customizable ±30%~±50%.
High overall efficiency: Voltage stabilizer efficiency ≥98%.
Stable control technology: Innovative MCU measurement control, metering chip design technology, ensuring precise and stable system operation.
Excellent output waveform: Output voltage waveform is distortion-free, without harmonics.
High-quality materials: 0.35mm high magnetic conduction, low-loss coated silicon steel sheets, C1017 alloy brushes.
High automation level: Fully automatic voltage stabilization, delayed startup, and automatic recovery after fault resolution.
Large load capacity: Voltage stabilizers available in capacities from 1KVA to 3600KVA.
Wide load type compatibility: Suitable for any load.
Comprehensive communication functions: Optional RS485, RS232, GRPS.
