Intro：The SBW-F series three-phase automatic compensation power stabilizer is an optimized and improved version of the SBW series products. It is suitable for grid conditions where the three-phase input voltage imbalance exceeds 5%.
Product Overview
The SBW-F series three-phase automatic compensation power stabilizer is an optimized and improved version of the SBW series products. It is suitable for grid conditions where the three-phase input voltage imbalance exceeds 5%. When three-phase fluctuations or uneven load currents cause voltage differences between phases, the three-phase output can automatically balance the voltage while maintaining smooth voltage regulation. It is also very suitable for the design of ultra-high-power stabilizers above 1000 KVA, featuring large capacity, high efficiency, no waveform distortion, and stable voltage regulation. It is widely applicable to various loads, can withstand instantaneous overloads, operate continuously for long periods, supports manual/automatic switching, and includes overvoltage protection, phase loss, phase sequence protection, and automatic protection against mechanical faults.
Technical Parameters
| Capacity Range | Three-phase capacity: SBW-F-20~3600KVA; |
| Input Voltage | Three-phase 380Vac ±15%; Customizable ±20% and above voltage range |
| Output Voltage | Three-phase 380Vac (can be customized according to customer requirements for output voltage) |
| Voltage Regulation | 1% ~ 5% adjustable |
| Frequency Range | 50Hz/60Hz |
| Efficiency | 98% |
| Response Speed | ≤ 0.04S |
| Stabilization Speed | Input voltage changes by ±10% of the rated value, stabilization time ≤ 1.2S |
| Insulation Resistance | ≥ 2MΩ |
| Withstand Voltage | 2000V 1 minute no breakdown |
| Waveform Distortion | The output voltage waveform compared with the input voltage waveform, the harmonic content does not exceed 1% |
| Communication Function | Optional RS232, RS485, GPRS interface, complete remote monitoring and control function |
| Display Function | LCD high-brightness display, can display input/output voltage, current, frequency, temperature and fault alarm status, etc. HMI human-machine interface touch screen display (optional) |
| Protection Function | Overvoltage, undervoltage, overcurrent, overheat, short circuit protection, optional missing phase, reverse phase, lightning protection and additional protection function |
| Operating Temperature | -15°C ~ +45°C |
| Relative Humidity | 10% ~ 90% (non-condensing) |
| Altitude | < 1000m, above standard altitude, according to GB1094.1.2013 "Power Transformers" Chapter 11.3 derating |
| Protection Rating | IP21, optional IP56 protection rating |
| Noise | < 60dB |
| Execution Standard | YD/T 1074-2000 "Communication AC Stabilizer", JB/T 7620 - 1994 "AC Stabilizer" |
Features
High voltage regulation accuracy: Uses RMS true RMS sampling control board, with adjustable voltage regulation accuracy of 1~5%.
Fast adjustment speed: Machine tool slide conduction technology, response time ≤0.04S, stabilization time<1.2S.
Comprehensive protection functions: Equipped with overvoltage, undervoltage, overcurrent, short circuit, overheating, phase loss and other protection functions.
Wide voltage regulation range: Standard 320~440VAC range, customizable ±20% or higher voltage range.
High overall efficiency: Voltage regulator efficiency ≥98%.
Stable control technology: MCU measurement and control, metering chip design technology, precise and stable system.
Excellent output waveform: Output voltage waveform without distortion, no harmonics.
High-quality materials: 0.35mm high magnetic conductivity, low loss coated silicon steel sheets, C1017 alloy brushes.
High degree of automation: System features fully automatic voltage regulation, delayed start, fault recovery automatic restoration.
Large load capacity: Voltage regulator capacity ranges from 20KVA to 3600KVA.
Wide range of load types: Suitable for any load.
Comprehensive communication functions: RS485/RS232/GPRS optional.
